1. Features

1.1 Load Capacity and Lifting Height:

Electric pallet stacker with consistent structural design and differentiated load capacities and lifting height, adapting to diverse material handling needs.

1.2 Power & Drive System:

Optional lead-acid batteries and lithium battery ensuring long-lasting power supply for continuous operations. The drive motor and lift motor work in tandem, with AC drive control mode for smooth power output.

EPS reduces energy consumption by 20% compared to traditional steering systems. It also enables precise operation and flexible steering, lowering operator fatigue during long shifts.

1.3 Structural & Safety Design:

Features a wide-field mast design with specialized high-strength groove steel, enhancing load-bearing stability during lifting. The chassis uses PU wheels with a minimum ground clearance of 30mm, suitable for flat warehouse floors.

Equipped with a branded control system and multifunctional protection system for higher functional safety. The service brake adopts an electromagnetic design, ensuring sensitive and reliable braking to prevent collisions. Additionally, the vertical branded gear box with optimized gear meshing reduces noise and improves operational safety.

1.4 Intelligent & Customizable Functions:

The lift system is designed for high efficiency, free maintenance, and no need for carbon-brush replacement, reducing daily upkeep costs and downtime.

Supports customized electromagnetic or laser navigation AGV, enabling seamless integration into automated warehouse systems for unmanned material handling.

2. Advantages

2.1 High Operational Efficiency:

Fast & stable movement.

It's suitable for medium-width warehouse aisles. It balances space utilization and operational efficiency.

2.2 Operator Comfort & Convenience:

The rider-type design allows operators to stand and operate, with a handle height of 1430mm for ergonomic control. The vertical drive unit automatically adjusts according to road conditions (no need to adjust buffering springs), ensuring steady operation and reducing vibration, thus improving comfort.

The integrated control system provides clear status feedback, enabling quick identification of issues during maintenance. This minimizes downtime and ensures continuous workflow.

2.3 Cost-Effective & Durable:

Full electric power eliminates fuel costs and reduces exhaust emissions, making it environmentally friendly and suitable for indoor warehouses. The low-maintenance design (no carbon-brush replacement, free-maintenance lift system) further cuts long-term operational expenses.

Long Service Life: High-quality components (e.g., high-strength mast steel, wear-resistant PU wheels, sealed battery system) ensure durability. The battery system has good sealing performance, reducing the risk of leakage and extending the overall service life of the equipment.

2.4 Versatile Application:

With load capacities covering 1000kg to 2000kg, it can handle most common warehouse goods (e.g., cartons, pallets of raw materials). The fixed fork dimensions and 500mm load center distance ensure compatibility with standard pallets.

The low noise level and zero exhaust emissions make it ideal for indoor spaces such as logistics warehouses, manufacturing workshops, and distribution centers.
