1) The branded control system features multiple automatic protection systems, providing a higher level of functional safety.
2) The vertical branded gearbox, with its multi-functional solutions and flexible modular system, utilizes optimized gear technology to reduce operating noise, providing customers with a high-performance and highly efficient user experience.
3) Equipped with a full AC drive system, it boasts features such as compact size, light weight, high efficiency, and maintenance-free operation, eliminating the hassle of replacing carbon brushes in DC motors and requiring no further maintenance or upkeep.
Model |
| CBD20II | CBD25ⅢI | CBD30III |
Power(electricity,diesel,LPG,petrol,manual) |
| Electric | Electric | Electric |
Operation(manual,walkie,side-standing,picker) |
| Ridertype | Ridertype | Ridertype |
Steering way |
| EPS | EPS | EPS |
Rated load capacity | Q(kg) | 2000 | 2500 | 3000 |
Load center distance | C(mm) | 600 | 600 | 600 |
Wheelbase | Y(mm) | 1380 | 1380 | 1380 |
Service weight(incl.battery) | kg | 710 | 730 | 750 |
Wheeltype(The front/rear) |
| PU | PU | PU |
Front wheelspecification | ø×w(mm) | φ80*80 | φ80*80 | φ80*80 |
The rearwheel specification | ø×w(mm) | φ230*75 | φ230*75 | φ230*75 |
Balance Wheel specification | ø×w(mm) | φ125*50 | φ125*50 | φ125*50 |
Mast height,extended | H(mm) | 205 | 205 | 205 |
Forks surface height from the ground when lowering | H1(mm) | 85 | 85 | 85 |
Forks outer width | S1(mm) | 685/540 | 685/540 | 685/540 |
Vehicle length(pedal folded/unfolded) | L(mm) | 1825/2240 | 1825/2240 | 1825/2240 |
Vehicle width | S(mm) | 760 | 760 | 760 |
Forks dimensions | s/e/l(mm) | 55/175/1150 | 55/175/1150 | 55/175/1150 |
Stacking aisle width,pallet 1m×1.2m
(1.0m cross forks)(pedal folded/unfolded) | Ast(mm) | 2220/2620 | 2220/2620 | 2220/2620 |
Load bearing distance | X(mm) | 970 | 970 | 970 |
The min.turning radius | Wa(mm) | 1670/2070 | 1670/2070 | 1670/2070 |
Travelling speed,unladen/full-loaded | km/h | 6/5.5 | 6/5.5 | 6/5 |
Lift speed unladen/full-loaded | m/s | 0.043/0.040 | 0.043/0.040 | 0.043/0.040 |
Lower speed unladen/full-loaded | m/s | 0.035/0.445 | 0.035/0.445 | 0.035/0.445 |
The max.gradability,unladen/full-loaded | % | 10/8 | 10/8 | 10/6 |
Service brake |
| Electromagnetic | Electromagnetic | Electromagnetic |
Drive motor power | kw | 1.5 | 1.5 | 1.5 |
Lift motor power | kw | 0.8 | 0.8 | 0.8 |
Batterytype |
| Lead-acid | Lead-acid | Lead-acid |
Battery voltage/capacity | V/Ah | 24/210 | 24/210 | 24/210 |
Charger | V/A | 24/30 | 24/30 | 24/30 |
Drive control mode |
| AC | AC | AC |
Noise level at driver's ears according to En12053 | dB(A) | 75 | 75 | 75 |
Q：What is the MOQ?
A： One set.
Q：Can I customize the equipment?
A：Yes, we offer customization service, including load capacity, lifting height, battery, color and others.
Q: Can I get spare parts or technical support after purchase?
A: Yes, we provide lifetime support and spare parts supply. We can ship parts globally and assist via video call.
Q：How long is the warranty time?
A： 12 months or 2000 hours whichever comes first.
Q：What is the payment terms?
A： T/T, 30% pre-payment in advance, and 70% balance before delivery.
