1) Compact structure, comfortable operation, with heavy load, suitable for factory, workshop scenarios;
2) Equipped with branded control system and multi-functional protection system, it offers higher level functional safety;
3) EPS steering energy reduces 20% with accurate operation, flexible steering, relieving operators pressures and greatly improving the production ability;
4) Equipped with full AC drive system, small volume, light weight,high efficiency, free-maintenance and carbon-brush replacement. No more maintenance and protection;
5) Only by stepping on the pedal switch can the vehicle moves. Otherwise, it stops. This design improves the safety.
6) Side-pull battery is easy to change, suitable for multi-shifting; Large power battery, long endurance and life expectancy;
7) Electromagnetic brake . It stops from sliding when powers cut off.
Characterisic | Model |
| CBD50A | CBD60A | CBD70A | CBD80A |
Power(electricity,diesel,LPG,petrol,manual) |
| Electric | Electric | Electric | Electric |
Operation(manual,walkie,side-standing,picker) |
| Side-standing | Side-standing | Side-standing | Side-standing |
Steering type |
| EPS | EPS | EPS | EPS |
Rated load capacity | Q(kg) | 5000 | 6000 | 7000 | 8000 |
Load center distance | C(mm) | 600 | 600 | 600 | 600 |
Wheelbase | Y(mm) | 1785 | 1940 | 1990 | 1990 |
Weight | Service weight(incl.battery) | kg | 2100 | 2150 | 2380 | 2430 |
Wheel/
Chassis
| Wheel type(The front/rear) |
| PU | PU | PU | PU |
Front wheel specification | ø×w(mm) | φ80*110 | φ80*110 | φ100*120 | φ100*120 |
The rearwheel specification | ø×w(mm) | φ254*102 | φ382*142 | φ382*142 | φ382*142 |
Balance Wheel specification | ø×w(mm) | φ150*50 | φ180*76 | φ180*76 | φ180*76 |
Dimensions | Mast height,extended | H(mm) | 225 | 240 | 270 | 270 |
Forkssurfaceheightfrom thegroundwhen lowering | H1(mm) | 105 | 120 | 150 | 150 |
Forks outer width | S1(mm) | 720 | 720 | 720 | 720 |
Vehicle length | L(mm) | 2215 | 2370 | 2450 | 2450 |
Vehicle width | S(mm) | 1090 | 1090 | 1260 | 1260 |
Forks dimensions | s/e/l(mm) | 70/215/1200 | 70/215/1200 | 120/270/1200 | 120/270/1200 |
Stacking aisle width,pallet 1m×1.2m
(1.0m cross forks) | Ast(mm) | 2765 | 2990 | 3050 | 3050 |
The min.turning radius | Wa(mm) | 2020 | 2190 | 2250 | 2250 |
Performance | Travelling speed,unladen/full-loaded | km/h | 5/4 | 5/4 | 4/3 | 4/3 |
Lift speed unladen/full-loaded | m/s | 0.042/0.04 | 0.050/0.048 | 0.052/0.050 | 0.052/0.048 |
Lowerspeed unladen/full-loaded | m/s | 0.35/0.045 | 0.035/0.050 | 0.04/0.055 | 0.04/0.055 |
Themax.gradability,unladen/full-loaded | % | 8/5 | 8/5 | 6/4 | 6/4 |
Service brake |
| Electromagnetic | Electromagnetic | Electromagnetic | Electromagnetic |
Motor | Drive motorpower | kw | 3 | 4.5 | 6.5 | 6.5 |
Lift motor power | kw | 3DC | 6.3 | 6.3 | 6.3 |
Battery type |
| Lead-acid | Lead-acid | Lead-acid | Lead-acid |
Battery voltage/capacity | V/Ah | 24/300 | 48/300 | 48/300 | 48/400 |
Charger | V/A | 24/40 | 48/40 | 48/40 | 48/50 |
| Drive control mode |
| AC | AC | AC | AC |
Noiselevel at driver'sears accordingto En12053 | dB(A) | 75 | 75 | 75 | 75 |
Q：What is the MOQ?
A： One set.
Q：Can I customize the equipment?
A：Yes, we offer customization service, including load capacity, lifting height, battery, color and others.
Q: Can I get spare parts or technical support after purchase?
A: Yes, we provide lifetime support and spare parts supply. We can ship parts globally and assist via video call.
Q：How long is the warranty time?
A： 12 months or 2000 hours whichever comes first.
Q：What is the payment terms?
A： T/T, 30% pre-payment in advance, and 70% balance before delivery.
