Gasoline Forklift Truck 3T LPG 3000kg ForkLift Block Clamp Hydraulic LP Gas Engine Solid Tires Optional CPQYD30_LPG forklift_Products

Description
Inquiry

Product Description

Nissan,Kubota and PSI top-brand Gasline/LPG engines with lowemission and low noise for option.The three way catalytic converterprovides precise control and excellent fuel efficiency.

Equipped with US IMPCO fuel conversion device.The proportionerprovides combustible gas mixture with the best air-fuel ratioincessantly,making for stable performance and strong economycapability,and easy to stat. Key structural elements such as forklift frame,mast and overheadguard are of optimized design and durable quality.Buffer device ofmast lifting system damps shock and vibration effectively,deliveringhigher operation safety and reliability. The new type steering wheel dual threaded adjustment mechanismwith patented technology improved the operation.Fork lifing,mastleaning forward and back,as wellas the optional fork shifting andfork spacing regulating function,can be controlled by the joystick.

1.01	Manufacturer
1.02	Model			CPQYD20	CPQYD25	CPQYD30	CPQYD35
1.03	Rated capacity	Q	kg	2000	2500	3000	3500
1.04	Load center distance	C	mm	500	500	500	500
1.05	Power type			Gasoline/LPG	Gasoline/LPG	Gasoline/LPG	Gasoline/LPG
1.06	Driving type			Seated	Seated	Seated	Seated
1.07	Wheel base	L1	mm	1600	1600	1740	1740
Tyres
2.01	Tyre type			Pneumatic	Pneumatic	Pneumatic	Pneumatic
2.02	Wheel number(front/rear)			2/2	2/2	2/2	2/2
2.03	Front tread	W3	mm	970	970	1000	1000
2.04	Rear tread	W2	mm	970	970	970	970
2.05	Tyre(front)			7.00-12-12PR	7.00-12-12PR	28X9-15-12PR	28X9-15-12PR
2.06	Tyre(rear)			6.00-9-10PR	6.00-9-10PR	6.50-10-10PR	6.50-10-10PR
Size
3.01	Front overhang	L2	mm	469	469	487	489
3.02	Mast tilting angle,front/rear	α/β	o	6/12	6/12	6/12	6/12
3.03	Height with mast retraction	H1	mm	2000	2000	2065	2180
3.04	Free lifting height	H3	mm	150	150	150	150
3.05	Max.lifting height	H	mm	3000	3000	3000	3000
3.06	Max.height after lifting	H2	mm	4042	4042	4250	4250
3.07	Overall guard height	H4	mm	2100	2100	2115	2115
3.08	Fork size:length×width×thickness	LxWxT	mm	1070×100×40	1070×120×40	1070×122x45	1070×122×50
3.09	Overall length(fork excluded)	L'	mm	2560	2560	2715	2715
3.1	Overall width	W1	mm	1160	1160	1225	1225
3.11	Turning radius	r	mm	2230	2230	2400	2420
3.12	Ground clearance of mast	H5	mm	110	110	120	120
3.13	Ground clearance of wheel base center(loaded)	H6	mm	135	135	148.5	148.5
3.14	Lateral fork adjustment Max./Min.	W5	mm	1024/200	1024/240	1060/250	1060/250
Performance
4.01	Travelling speed (loaded/unloaded)		km/h	17/19	17/19	18/19	18/19
4.02	Lifting speed(loaded/unloaded)		mm/s	530/550	530/550	470/520	370/400
4.03	Lowering speed (loaded/unloaded)		mm/s	450/550	450/550	450/550	350/400
4.04	Gradeability(loaded/unloaded)		%	27/25	23/18	22/18	20/16
4.05	Max.traction force (loaded/unloaded)		N	19/14	19/15	18/14	19/14
Weight
5.01	Total weight		Kg	3400	3649	4200	4550
5.02	Axle load (unloaded),front/rear		Kg	1416/1984	1475/2305	1850/2560	2450/3160
5.03	Axle load (loaded),front/rear		Kg	4740/660	5475/805	6480/930	7180/1330
Combustion -engine
6.01	Engine manufacturer/Model			G Q - 4 Y
6.02	Rated power/Speed		Kw/rpm	46/2800(GAS)39/2800(LPG)
6.03	Max.torque/Speed		Nm/rpm	168/1800(GAS)156/1800(LPG)
6.04	Cylinder number-bore×stroke			4-91×86
6.05	Engine displacement		L	2.237
6.06	Emission			stage ll
6.07	Transmission gears(front/rear)			Power Shift
6.08	Fuel tank capacity		L	60
Additional data
7.01	Service brake/parking brake			Hydraulic/Mechanical
7.02	Hydraulic system working pressure		Mpa	17.5	17.5	17.5	17.5

photobank 1 (13)

1 (14)

1 (15) 1 (11) 1 (19)

FAQ

Q：What is the MOQ?
A： One set.

Q：Can I customize the equipment?

A：Yes, we offer customization service, including load capacity, lifting height, battery, color and others.

Q: Can I get spare parts or technical support after purchase?
A: Yes, we provide lifetime support and spare parts supply. We can ship parts globally and assist via video call.

Q：How long is the warranty time?
A： 12 months or 2000 hours whichever comes first.

Q：What is the payment terms?
A： T/T, 30% pre-payment in advance, and 70% balance before delivery.
