1）Compact structure, high maneuverability. Low gravity center with good stability. It suits large tonnage, high lifting goods storage scenarios.
2) It features in overall mast moving forward, with small turning radius to neglect obstacles at the bottom of the racks. It suits any space-limited scenarios, easy loading or unloading goods.
3) Equipped with full AC drive system, small volume, light weight, high efficiency , free - maintenance and carbon - brush replacement. No more maintenance and protection.
4) Standard forks tilting up or down function, prevents goods from tipping over and improving the load capability.
5) Side-pull battery suits multi-shifing occasions , with standard roller trolley for easy change.
6) 6.5m or above high-strength H type mast steel, not easy to deform, with reliable and stable operation.
Model |
| CDDM10-60S | CDDM12-60S | CDDM15-60S | CDDM16-60S |
Power |
| Electric |
Operation |
| Side-standing |
Rated load | Q(kg) | 1000 | 1200 | 1500 | 1600 |
Load centerdistance | C(mm) | 500 | 500 | 600 | 600 |
Service weight(incl.battery) | kg | 5100 | 5200 | 6300 | 6500 |
Wheel type |
| PU | PU | PU | PU |
Drivewheel specifications | ×w(mm) | Ф382*142 |
The front wheelspecification | Xw(mm) | φ145*100 | φ145*100 | φ145*100 | φ145*100 |
The balance wheel specification | ×w(mm) | φ180*76 | φ180*76 | φ180*76 | φ180*76 |
Tread,front | b10(mm) | 1210 | 1210 | 1305 | 1305 |
Mast height,lowered | h1(mm) | 3400 | 3400 | 3400 | 3400 |
Free lifting height | h2(mm) | 2235 | 2235 | 2235 | 2235 |
Lift height | h3(mm) | 6000 | 6000 | 6000 | 6000 |
Mastheight,extended | h4(mm) | 7125 | 7125 | 7125 | 7125 |
Overhead guard height | h14(mm) | 2260/2300 |
Length(forks rotate on both left and right sides) | l2(mm) | 3045 | 3045 | 3065 | 3065 |
Vehicle width | b1(mm) | 1455 | 1455 | 1550 | 1550 |
Anti-collision guardrail width | (mm) | 1500 | 1500 | 1600 | 1600 |
Forks dimensions | s/e/l(mm) | 40/122/1070 | 45/125/1200 |
Forks adjustment dimensions | b5(mm) | 260-650 (Customized) |
The min.ground clearance (wheelbase center) | m2(mm) | 32 | 32 | 32 | 32 |
Stacking aisle width | Ast(mm) | 1500(1000*1000pallet) | 1600(1200*1200pallet) |
Aisle guide rail width | (mm) | 120 | 120 | 120 | 120 |
The min.tuning radius | Wa(mm) | 1985 | 1985 | 1985 | 1985 |
The main aisle width |
| 3270+400 | 3270+400 | 3470+400 | 3470+400 |
The max. travelling speed,unladen/full-loaded | km/h | 8/7 | 8/7 | 8/7 | 8/7 |
Lift speed,unladen/full-loaded |
| 0.30/0.26 | 0.30/0.26 | 0.30/0.26 | 0.30/0.26 |
Lowerspeed,unladen/full-loaded |
| 0.30/0.32 | 0.30/0.32 | 0.36/0.39 | 0.36/0.39 |
Service brake |
| Electromagnetic |
Drive motor power |
| 6.5AC | 6.5AC | 6.5AC | 6.5AC |
Lift motor power |
| 15AC | 15AC | 15AC | 15AC |
Battery type |
| Lead-acid | Lead-acid | Lead-acid | Lead-acid |
Battery voltage/capacity | V/Ah | 48/400 | 48/400 | 48/400 | 48/400 |
Motor | V/A | 48/50 | 48/50 | 48/50 | 48/50 |
Drive control mode |
| AC | AC | AC | AC |
Q：What is the MOQ?
A： One set.
Q：Can I customize the equipment?
A：Yes, we offer customization service, including load capacity, lifting height, battery, color and others.
Q: Can I get spare parts or technical support after purchase?
A: Yes, we provide lifetime support and spare parts supply. We can ship parts globally and assist via video call.
Q：How long is the warranty time?
A： 12 months or 2000 hours whichever comes first.
Q：What is the payment terms?
A： T/T, 30% pre-payment in advance, and 70% balance before delivery.
